FULL RANGE ACTIVE FR-115A TRUE VOICE

KEY FEATURES
·High-efficiency Class D amplifier with SMPS
·Easy system configuration thanks to ALLDSP ALLControl.
·High-end 32-bit DSP with LCD screen
·FIR processing for constant phase response
DESCRIPTION
·Integrated control panel and wireless connection Stereo Music
·Connect to play music using Bluetooth function
·Integrated 32-bit DSP digital control with LCD screen
·Preset mode: Live, Dance, Vocals, Bass Boost, Vocal & Mode
·3 band EQ adjustment (LOW, MID, HIGH) in the range of -10dB to +6dB
·Delay adjustment in the range of 0- 9.9m in 0.1m steps (units can be switched between m and
feet)
·WIRELESS AUDIO connection extension mode allows connecting a device such as a tablet
or smartphone to send sound to the speakers (up to 2) without using cables
·Integrated ALLDSP ALLControl driver
·Other options: Screen brightness adjustment 0 to + 10; Sharpness -10 to +10; Logo on and off;
Standby mode Off and 5 minutes; Display Firmware version information for easy upgrade; RESET
mode to return to the original state
·Interface lock mode after setting LOCK : Off; On
·HPF mode: Off; 63Hz; VOCAL;100Hz
·2 Input audio level adjustment buttons CH1, CH2; audio output selection button (3 options :
CH1, CH2, MIX)

SPECIFICATIONS
Power Continuous: 750 Watts (Class D)
Power Peak: 1500 Watts (Class D)
Frequency Range (-10 dB): 45 Hz – 20 kHz
Maximum peak SPL at 1m: 135 dB
Input Impedance: 20kΩ
Input sensitivity: 3V (+12 dBu)
Horizontal coverage angle (-6 dB): 90˚
Vertical coverage angle: 50º
LF unit (Bass): 1 x 15 inch (Low-mid 15”, 3” voice coil)
HF unit (Treble): 1 x 1 inch (1” compression speaker, 1” throat)
AC power required: 230V / 115V : 1.5 A / 3.0 A
Connectors:
+ Jack 1/4”, Jack XLR, Aux In 3.5mm Mini
+ INPUT: 2 x Female XLR/ 2 x 1/4” jack
+ OUTPUT: 1 x Male XLR
+ AC INPUT : power CON
Shell material: Birch plywood
Paint finish: ISO-flex Paint, Color : Black
Dimension (H x W x D): 720 x 445 x 380 mm
Weight: 25.5 kg
